Therm Coil Drawing No.: 366R-3084-003 Therm Coil Model No.: TC-776
HELPFUL HINT: Use CTRL+F to use the search function for your part number.
- Replacement For Part Numbers:
Kenmore / Roper / Whirlpool: 4334146, 282717, 301471, 314620, 319529, 319837, 319838, 320420, 320421, 320424, 324186, 324187, 4332934, 4352194, 4352200, 4353023, 4353024, 4354077, 4354078, 4354356, 4354377, 4354428, 4354429, 4354638, 4354639, 4354640, 4355557, 4355987
Other: CH776, TJ90CH776, 508339, 115951, OEM12416730, OEM13693782, OEM18010406, OEM18010406, AP3104182, AP3423445, AP4502601, 456091, 458871, CH776, RP776, TS776, YCH776
- 2500 W @ 240 V (1875W @ 208V)
- Approximate Overall Size: 19-1/4” Wide x 15-3/8″ Length From Front Of Element To Mounting Bracket x 3-3/4″ Insert From Bracket To Terminal Ends.
- Male Quick-Connect Push-In Terminals
- Used in various models of Roper, Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore/Sears, and other Ranges And/Or Ovens. NOTE – Not all compatible model numbers are listed. If your specific range or oven model number is not listed, use part numbers and dimensions to determine if this element will fit your appliance.
- Used In Appliance Model Numbers (among others):
2570B00, 2570B10, 2883*10, 2883W10
