Model TC-1035: Vintage Corning 981034 Equivalent / Chromalox CH1035 Range/Oven Bake Replacement Element, 3,000W @ 250V

Therm Coil Drawing No.: 366R-4209-003           Therm Coil Model No.: TC-1035

HELPFUL HINT: Use CTRL+F to use the search function for your Part Number.

• Replacement For Part Numbers:

Corning: 981034

Other: CH1035, 115438, 453624, RP771, TS1035, TS1035/771, TS771, TS771/1035, YCH1035, AP3389541

• 3000 W @ 250 V Rating
• Approximate Overall Size: 19-3/4″ Width x 16″ Back Of Element To Mounting Brackets x 3-1/4 Insert (Bracket To Terminal End) x 1-3/4″ Center-to-Center Terminal Width.
• Male Quick-Connect Push-In Terminals
• Used in vintage Corning ovens/ranges/stoves.

Therm Coil MFG. Co. is not affiliated with Genera Corporation, Sears, or any other listed manufacturers or their affiliates.
