Schafer’s Little York Hit and Miss Casting Kit
Kit Contains:
Aluminum Castings (3)
Base, head and fender
Cast Iron Castings (6)
2 flywheels, cylinder, 2 valve cages, and piston
Bronze Castings (9)
Conn. rod, rocker arm, timing arm, 2 gov. weights, gov. brackets, arm retainer, speed adjustable block and camshaft bearing
Set of Boston Gears
Photographs (2)
Detailed Blueprints (4) 17″ x 22″
Schaefer Model Specifications:
Flywheels – 4 1/2 inch
Bore – .750 inch
Stroke – 1.50 inch
A lathe and milling machine are needed to finish the castings and to fabricate the additional parts required.
Shipping weight 10 lbs.
Paint: Dulux – 51907 Navy Blue
