GrowerSELECT® replacement direct drive motor for AP®/Airstream® 12″ and 14″ Performer fans. Motor is supplied with a voltage selection switch under the connection cover.
Replacement for AP®/Airstream® part number: 15-0109
*Use of manufacturer part numbers for reference purposes only
Motor Specifications:
| HP | 1/4 |
| RPM | 1725/1425 |
| Hertz | 60/50 |
| Volts | 115/230 & 100/200 |
| Full Load Amps | 3.4/1.7 & 3.0/1.5 |
| Service Factor | 1 |
| Frame | 56Z |
| Rotation | CCW (Not Reversible) |
| Shaft Diameter | 1/2″ |
| Shaft Length | 3-1/2″ |
| Shaft Shape | Straight |
| Motor Diameter | 6.5″ |
| Motor Length (w/ shaft) | 13.5″ |
| Motor Weight | 17.7 lbs |
| Mounting Bolt Length | N/A |
| Mounting Bolt Thread | N/A |
