3 HP 230V 1760 RPM motor for 6″ rigid auger systems. Max length 30′.
Replacement for previous Hog Slat part numbers: BM998, ITMX8, 6K610 & G300-1
*Use of manufacturer part numbers for reference purposes only
- Class F Insulation
- 40°C Ambient, Continuous Duty
- Typical Starting Torque 300% Of Full Load
- F1 Assembly
- Extruded Aluminum Frame (180-210 Frame)
- Manual Reset Thermal Overload Protector
- Plastic Fan & Fan Cover
- Double Shielded Bearings w/Low-Temp Grease (Regreasable Shaft End)
- Removable Condensation Drains For Vertical Mounting
- Fully Gasketed Steel Conduit Box
- Die Cast Aluminum Brackets With Steel Bearing Inserts
Motor Specifications:
| HP | 3 |
| RPM | 1760 |
| Hertz | 60 |
| Volts | 230 |
| Amps | 17.0 |
| Service Factor | 1.15 |
| Frame | 184T |
| Shaft Diameter | 1-1/8″ |
| Motor Weight | 67 lbs |
