10″ x 6″ Hi-Temp Access Door w/ 6″ Break-Away Studs
10″ x 6″ Hi-Temp Access Door with 6″ Break-Away Studs is solid, leak resistant and consists of two layers of stamped, hot dipped galvanized steel and one 16-Gauge black iron backing plate.
Hi-Temperature ceramic fiber gasket (2300 degrees F, 1260 degrees, meets NFPA 96 Standards) is permanently bonded to the outside panel of the Access Door to eliminate leakage.
6” Break-Away studs permit installations with fire wrap insulation. Studs may be broken at 2” for standard installations.
Zinc plated conical springs are installed, between the inner and outer plates, to facilitate opening.
Zinc coated wing nuts are easily turned by hand.
NO MEASURING (Self-Adhesive template provided)
Opening Size: 10″ x 6″
Door Size: 11″ x 7″
